| Model | Tavol-804 | |
| Machine parameters | Type | 4×4 |
| Rated Traction( KN) | 12 | |
| PTO Max Power (KW) | 50 | |
| Dimensions(mm) | 3560×1450×2150 | |
| Wheelbase(mm) | 1780 | |
| Track(mm) | Front wheel(mm) | 1350-1550 |
| Rear wheel(mm) | 1300-1500 | |
| Quantity: | |
|---|---|
TL804
TAVOL
8701931000
80hp tractors, that is, tractors with a rated power of 80 horsepower, are usually equipped with well-known brand engines, such as Dongfanghong, etc., providing stable and powerful power output. They are compact in design and sturdy in structure, and can adapt to a variety of farmland operating environments. Different brands and models of 80hp tractors may differ in details, but in general they are efficient, durable, and easy to operate.
1. Powerful power and high efficiency
80hp tractors are equipped with high-performance engines, such as the Dongfanghong series or Perkins brand, with a rated power of 59kw (about 80hp), ensuring strong power output. The engines they are equipped with are not only highly reliable, but also have the characteristics of large torque reserve and low fuel consumption, which effectively improves economic benefits. For example, the Tieniu 804 tractor, as one of the early 80hp wheeled tractors produced in China, is well-designed, reliable in use, and easy to maintain, and is deeply loved by users.
2. Multi-gear transmission system
This series of tractors adopts advanced transmission systems, such as F12+R12 gears or 2×(8+4) meshing sleeve design, providing 16 forward gears and 8 reverse gears, with reasonable gear distribution and a wide speed range to meet the needs of different farmland operations. This design not only improves transmission efficiency, but also makes operation more flexible and convenient, and is suitable for various complex terrains and working environments.
3. Fully hydraulic steering and braking system
80hp tractors are equipped with a fully hydraulic steering system, which is easy and flexible to operate, with a small turning radius, and improved maneuverability. At the same time, the use of hydrostatic disc brakes has a large braking torque and good braking effect, ensuring safe operation. The combination of the hydraulic service brake system and the parking brake system operated by the handle further enhances the safety and reliability of the vehicle.
4. Advanced suspension and lifting system
The tractor adopts an independent power take-off and a high-pressure lifting device, which has a large lifting force and is easy to maintain. The double-cylinder external lifter has a strong pressure lifting function and can be used with large machines for operation. In addition, the suspension control pedal and elastic shock-absorbing seat design improve the operating comfort and reduce the fatigue caused by long-term operation.
5. Compact structure and beautiful appearance
The 80hp tractor adopts a three-dimensional technology optimization design with a compact structure and a reasonable layout. The final drive adopts a planetary reduction mechanism, which is not only compact in structure, but also achieves a large reduction ratio. At the same time, the streamlined appearance design is stylish and generous, and the cab is welded with high-strength profiles, with good sealing and wide field of vision. Fans and heaters can be optionally installed to improve the comfort of the driving environment.
Model | Tavol-804 | |
Machine parameters | Type | 4×4 |
Rated Traction( KN) | 12 | |
PTO Max Power (KW) | 50 | |
Dimensions(mm) | 3560×1450×2150 | |
Wheelbase(mm) | 1780 | |
Track(mm) | Front wheel(mm) | 1350-1550 |
Rear wheel(mm) | 1300-1500 | |
Ground clearance(mm) | Minimum ground clearance(mm) | 400 |
Minimum turning cricle radius | Use unilateral braking | ≤4.0 |
Not unilateral braking | ≤4.6 | |
Minimum use quality | 2065 | |
Gearbox | 12F+12R Shuttle Shift | |
Steering System | hydraulic steering gear | |
Drive Train | Clutch | double acting clutch |
Working equipment | Maximum lifting force at 610mm(KN) | ≥14 |
Suspension mechanism | Three-piont suspension type 1 | |
PTO shaft | PTO Spedd(r/min) | 540/760/1000 |
Tire | Front wheel specifications | 8.3-24 |
Rear wheel specifications | 12.4-32 | |
Engine | Type | Inline, 4 stroke, Water cooled |
Cylinder | 4 | |
Optional | Cabin | AC/Heater |
Roll bar | ||
Canopy | ||
Perfusion volume | Radiater(L) | 10 |
Fuel tank(L) | 60 | |
Engine oil pan(L) | 5 | |
Driveline oil (L) | 20 | |
Lifter(L) | 9.5 | |
This parameter table is for reference only, everything is based on actual products | ||
1. Farmland cultivation: 80hp tractors are suitable for various farmland cultivation operations, including deep plowing, rotary tillage, harrowing, etc. Its powerful power output and efficient transmission system can easily cope with various soil conditions, improve farming efficiency, and provide good basic conditions for the growth of crops.
2. Crop planting and harvesting: During the crop planting process, 80hp tractors can be used for sowing, fertilization and other operations to ensure that seeds and fertilizers are evenly distributed in the field. In the harvest season, it can also cooperate with various harvesting machinery, such as combine harvesters, to carry out efficient and accurate crop harvesting, reduce crop losses, and improve economic benefits.
3. Orchard management: For orchards, the flexibility and versatility of 80hp tractors are particularly important. It can be used for daily management operations such as weeding, fertilization, and spraying in orchards. It can also be used with special orchard machinery for pruning and picking fruit trees to improve the efficiency and quality of orchard management.
4. Forestry operations: In the field of forestry, 80hp tractors can be used for operations such as clearing forest land and transporting timber. Its strong traction and load-bearing capacity enable it to play an important role in complex forestry environments and improve the efficiency and safety of forestry operations.
5. Engineering construction: In addition to the fields of agriculture and forestry, the 80hp tractor can also be used in some small engineering construction projects. For example, it can be used for tasks such as carrying construction materials and towing construction machinery, providing strong support for the smooth progress of engineering construction.
1. Check before starting: Make sure that all parts of the tractor are in good safety and technical condition, and check the lubricating oil, fuel, coolant and tire pressure.
2. Starting operation: Depress the clutch, shift to neutral gear, and start the engine. When starting by hand, the standing position should be safe, and the crank should be removed after the engine starts.
3. Driving operation: Release the clutch slowly when starting, and avoid sudden acceleration. Pay attention to road conditions while driving, maintain a safe speed, and overloading and illegal carrying of passengers are strictly prohibited.
4. Steering and braking: Slow down before turning, and use the steering wheel to steer smoothly. When braking, gently step on the brake pedal to avoid sudden braking.
5. Stopping and maintenance: When parking, shift to neutral gear, pull the handbrake, turn off the engine and remove the key. Perform regular maintenance to ensure stable performance of the tractor.
Q1:Are you the factory or the trading company?
A1:We are the factory,we located in Taian City,Shandong Province,China.
Q2:What after-sales service can your company provide?
A2:We can provide technical support and on-site installation support!
Q3:Can you provide spare parts for free?
A3:Of course.
Q4:Can you provide OEM?
A4:Yes,we can.
Q5:How about the delivery time?
A5:5-15 days according to the different quantity.
